| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 3STM12.7 | 13.00 | 25.00 | 6.00 | 7 | 102 | 70 | 1000 | - | 0.39 | 61 | - | Yes | 5 |
| 3STM19 | 19.00 | 33.00 | 7.00 | 7 | 102 | 70 | 1000 | - | 0.62 | 61 | - | Yes | 5 |
| 3STM25 | 25.00 | 38.00 | 6.50 | 7 | 102 | 70 | 1000 | - | 0.68 | 61 | - | Yes | 5 |
| 3STM32 | 32.00 | 44.00 | 6.00 | 7 | 102 | 70 | 1000 | - | 0.79 | 61 | - | Yes | 5 |
| 3STM38 | 38.00 | 50.00 | 6.00 | 7 | 102 | 70 | 1000 | - | 0.92 | 61 | - | Yes | 5 |
