| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 2HD25 | 25.40 | 31.50 | 3.05 | 8 | 116 | 25 | 360 | 48 | - | 30 | - | No | 30 |
| 2HD30 | 31.80 | 38.80 | 3.50 | 7 | 102 | 21 | 300 | 68 | - | 30 | - | No | 30 |
| 2HD40 | 38.00 | 46.30 | 4.15 | 5.5 | 80 | 18 | 260 | 70 | - | 30 | - | Yes | 30 |
| 2HD50 | 50.80 | 60.80 | 5.00 | 4.5 | 65 | 18 | 260 | 100 | - | 30 | - | Yes | 30 |
| 2HD60 | 60.00 | 70.00 | 5.00 | 4.5 | 65 | 18 | 260 | 115 | - | 30 | - | No | 30 |
| 2HD65 | 63.50 | 74.50 | 5.50 | 4.5 | 65 | 18 | 260 | 120 | - | 30 | - | Yes | 30 |
| 2HD75 | 76.20 | 87.20 | 5.50 | 4.5 | 65 | 18 | 260 | 155 | - | 30 | - | Yes | 30 |
| 2HD100 | 101.20 | 114.20 | 6.50 | 4 | 58 | 14 | 200 | 213 | - | 30 | - | Yes | 30 |
| 2HD125 | 127.00 | 141.00 | 7.00 | 3 | 44 | 10 | 145 | 230 | - | 15 | - | Yes | 15 |
| 2HD140 | 140.00 | 155.00 | 7.50 | 3 | 44 | 9 | 130 | 350 | - | 15 | - | No | 15 |
| 2HD150 | 152.40 | 169.40 | 8.50 | 2.5 | 36 | 9 | 130 | 375 | - | 15 | - | Yes | 15 |
| 2HD200 | 203.20 | 224.40 | 10.60 | 2.5 | 36 | 8 | 115 | 600 | - | 6 | - | No | 6 |
| 2HD250 | 254.20 | 284.00 | 14.90 | 2.5 | 36 | 8 | 115 | 1000 | - | 6 | - | No | 6 |
| 2HD300 | 300.00 | 340.00 | 20.00 | 2.5 | 36 | 6 | 85 | 1000 | - | 6 | - | No | 6 |
