Home / Products / Hoses / Heavy Duty Grey Suction

Hoses

Standard Color GREY

Download Brochure

Heavy Duty Grey Suction

Tube

Strong,Flexible & Smooth Plasticized PVC

Reinforcement

Shock Resistant Hard Rigid PVC Spiral

Cover

Hard Rigid PVC

TEMP RANGE

-5°C to + 70°C Approx

Applications

Heavy Duty Suction & Delivery Hose for Meeting The Challenging Service Conditions in Coal & Mineral Mines And Stone & Lime Quarries
Shipping & Sewage Disposal & Aqua Culture
Paper Mills,Cement Conveying,Chemical Industries,Petrochemical & Oil Exploration
Fire Fighting Equipments, Constructional Engineering & General Industrial Service Etc

MARKING ON THE HOSE

Heavy Duty Grey Hose India

Properties

Good Resistance To Saline Water, Light Acids,Alkalies & Other Chemicals Except Solvents
Ideal Result For Chemical Usage Can Be Obtained For Concentration Up To 60% To 70% At Room Temperature
Abrasion Resistant

Features

Smooth Inside Surface Results In Quick Conveyance Of Fluids
Minimum Friction Loss,Saves Higher Energy & High Flow Rate
Can Easily Withstand Absolute Vacuum
No Kinking Or Crushing Even With Severe Service Conditions

Hoses Description


Item Code	ID	OD	Wall Thickness	Working Pressure	Working Pressure	Bursting Pressure	Bursting Pressure	Bending Radius	Weight	Standard Length	Vacuum Pressure	Ex-Stock	MOQ
	MM	MM	MM	Bar	PSI	Bar	PSI	MM	Kg/Mtr	Mtr.	Bar	--	Mtr.
2HD25	25.40	31.50	3.05	8	116	25	360	48	-	30	-	No	30
2HD30	31.80	38.80	3.50	7	102	21	300	68	-	30	-	No	30
2HD40	38.00	46.30	4.15	5.5	80	18	260	70	-	30	-	Yes	30
2HD50	50.80	60.80	5.00	4.5	65	18	260	100	-	30	-	Yes	30
2HD60	60.00	70.00	5.00	4.5	65	18	260	115	-	30	-	No	30
2HD65	63.50	74.50	5.50	4.5	65	18	260	120	-	30	-	Yes	30
2HD75	76.20	87.20	5.50	4.5	65	18	260	155	-	30	-	Yes	30
2HD100	101.20	114.20	6.50	4	58	14	200	213	-	30	-	Yes	30
2HD125	127.00	141.00	7.00	3	44	10	145	230	-	15	-	Yes	15
2HD140	140.00	155.00	7.50	3	44	9	130	350	-	15	-	No	15
2HD150	152.40	169.40	8.50	2.5	36	9	130	375	-	15	-	Yes	15
2HD200	203.20	224.40	10.60	2.5	36	8	115	600	-	6	-	No	6
2HD250	254.20	284.00	14.90	2.5	36	8	115	1000	-	6	-	No	6
2HD300	300.00	340.00	20.00	2.5	36	6	85	1000	-	6	-	No	6
