| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 2OIL25 | 25.40 | 31.50 | 3.05 | 8 | 116 | 22 | 315 | 48.00 | - | 30 | - | No | 30 |
| 2OIL30 | 31.80 | 39.00 | 3.60 | 7 | 102 | 21 | 300 | 68.00 | - | 30 | - | No | 30 |
| 2OIL40 | 38.10 | 46.40 | 4.15 | 5.5 | 80 | 18 | 260 | 70.00 | - | 30 | - | No | 30 |
| 2OIL50 | 50.80 | 60.80 | 5.00 | 4.5 | 65 | 18 | 260 | 100.00 | - | 30 | - | No | 30 |
| 2OIL65 | 63.50 | 74.50 | 5.50 | 4.5 | 65 | 18 | 260 | 120.00 | - | 30 | - | No | 30 |
| 2OIL75 | 76.20 | 87.20 | 5.50 | 4.5 | 65 | 18 | 260 | 155.00 | - | 30 | - | No | 30 |
| 2OIL100 | 101.20 | 114.20 | 6.50 | 4 | 58 | 14 | 200 | 213.00 | - | 30 | - | No | 30 |
