| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 5014SP06 | 9.50 | 21.10 | 5.80 | 445 | 6454 | 1780 | 25810 | 180 | 1.00 | 50 | - | YES | 5 |
| 5014SP08 | 12.70 | 24.30 | 5.80 | 415 | 6019 | 1660 | 24070 | 230 | 1.00 | 40 | - | YES | 5 |
| 5014SP10 | 16.00 | 27.90 | 5.95 | 350 | 5076 | 1400 | 20300 | 250 | 1.30 | 40 | - | YES | 5 |
