Hoses

Standard Color BLUE

Download Brochure

Paint Spray - 2W

Tube

Polyamide

Reinforcement

Double Braids Of Steel Wire

Cover

Polyurethane
Blue Colour
Pin Pricking (Optional)

TEMP RANGE

-40°C Approx to +100°C Approx
Not To Exceed +70°C For Air And Water Based Fluids

Applications

High Pressure Airless Paint Spray Systems For 150 To 450 Bar.
Suitable For Applications Requiring Chemical Resistance To Solvents And Aggressive Fluids.
Due To Low Permeation Value Of Polyamide, The Hose Is Also Suitable For Industrial Gases.

MARKING ON THE HOSE

HoseX Paint Spray 2W Hose ID..WP..PSI/BAR

Hoses Description


Item Code	ID	OD	Wall Thickness	Working Pressure	Working Pressure	Bursting Pressure	Bursting Pressure	Bending Radius	Weight	Standard Length	Vacuum Pressure	Ex-Stock	MOQ
	MM	MM	MM	Bar	PSI	Bar	PSI	MM	Kg/Mtr	Mtr.	Bar	--	Mtr.
501TPPS2W04	6.40	13.70	3.65	450	6527	1800	26000	100	0.34	-	-	YES	5
501TPPS2W06	9.50	17.50	4.00	380	5511	1520	22000	127	0.48	-	-	YES	5
