| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 501TSA25 | 25.00 | 32.00 | 3.50 | 8 | 116 | 24 | 348 | 75.00 | 0.48 | 30 | 1.00 | Yes | 5 |
| 501TSA32 | 32.00 | 40.00 | 4.00 | 8 | 116 | 24 | 348 | 95.00 | 0.70 | 30 | 1.00 | Yes | 5 |
| 501TSA38 | 38.00 | 47.00 | 4.50 | 7 | 102 | 21 | 300 | 115.00 | 0.90 | 30 | 1.00 | Yes | 5 |
| 501TSA50 | 50.00 | 60.00 | 5.00 | 7 | 102 | 21 | 300 | 155.00 | 1.30 | 30 | 1.00 | Yes | 5 |
| 501TSA63 | 63.00 | 75.00 | 6.00 | 7 | 102 | 21 | 300 | 185.00 | 2.00 | 30 | 1.00 | Yes | 5 |
| 501TSA75 | 75.00 | 87.00 | 6.00 | 6 | 87 | 18 | 260 | 245.00 | 2.53 | 20 | 1.00 | Yes | 5 |
