| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 1WTR32(P) | 31.00 | 41.00 | 5.00 | 10 | 145 | 30 | 435 | 190 | - | 40 | - | No | 40 |
| 1WTR38(P) | 38.00 | 48.00 | 5.00 | 10 | 145 | 30 | 435 | 230 | - | 40 | - | No | 40 |
| 1WTR50(P) | 50.00 | 62.00 | 6.00 | 10 | 145 | 30 | 435 | 310 | - | 40 | - | No | 40 |
| 1WTR63 | 63.00 | 76.00 | 6.50 | 10 | 145 | 30 | 435 | 380 | - | 20/40 | - | Yes | 5 |
| 1WTR75 | 75.00 | 87.00 | 6.00 | 10 | 145 | 30 | 435 | 460 | - | 20/40 | - | Yes | 5 |
| 1WTR100 | 100.00 | 115.00 | 7.50 | 10 | 145 | 30 | 435 | 610 | - | 20/40 | - | No | 20 |
