| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 1STM12.5 | 12.50 | 22.00 | 4.75 | 3.5 | 50 | 35 | 500 | - | - | - | - | Yes | 5 |
| 1STM20 | 20.00 | 31.00 | 5.50 | 3.5 | 50 | 35 | 500 | - | - | - | - | Yes | 5 |
| 1STM25 | 25.00 | 38.00 | 6.50 | 3.5 | 50 | 35 | 500 | - | - | - | - | Yes | 5 |
| 1STM31.5 | 31.50 | 44.00 | 6.50 | 3.5 | 50 | 35 | 500 | - | - | - | - | Yes | 5 |
| 1STM38 | 38.00 | 52.00 | 7.00 | 3.5 | 50 | 35 | 500 | - | - | - | - | Yes | 5 |
| 1STM50 | 50.00 | 66.00 | 8.00 | 3.5 | 50 | 35 | 500 | - | - | - | - | Yes | 5 |
