| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 11PVCSP32 | 32.00 | 38.00 | - | 1.500 | 22 | - | - | 32.00 | 0.280 | 15 | 0.200 | No | 100 |
| 11PVCSP38 | 38.00 | 44.00 | - | 1.400 | 20 | - | - | 38.00 | 0.340 | 15 | 0.200 | Yes | 5 |
| 11PVCSP41 | 41.00 | 47.00 | - | 1.400 | 20 | - | - | 41.00 | 0.370 | 15 | 0.180 | Yes | 5 |
