| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 11PVCEW40 | 40.00 | 48.00 | 280 | 5 | 73 | 15 | 210 | 195.00 | 0.620 | 30 | 0.700 | Yes | 5 |
| 11PVCEW50 | 50.00 | 59.00 | 280 | 5 | 73 | 15 | 210 | 235.00 | 0.880 | 30 | 0.700 | Yes | 5 |
| 11PVCEW60 | 60.00 | 69.00 | 280 | 5 | 73 | 15 | 210 | 275.00 | 1.130 | 30 | 0.700 | Yes | 5 |
