| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 16CHL-COR/AC01N-19 | 19.00 | 31.00 | 6.00 | 10 | 145 | 40 | 580 | - | 0.60 | 61.00 | - | Yes | 5 |
| 16CHL-COR/AC01N-25 | 25.00 | 37.00 | 6.00 | 10 | 145 | 40 | 580 | - | 0.70 | 61.00 | - | Yes | 5 |
| 16CHL-COR/AC01N-32 | 32.00 | 44.00 | 6.00 | 10 | 145 | 40 | 580 | - | 0.86 | 61.00 | - | Yes | 5 |
| 16CHL-COR/AC01N-38 | 38.00 | 52.00 | 7.00 | 10 | 145 | 40 | 580 | - | 1.17 | 61.00 | - | Yes | 5 |
