| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 16BM-DRAGAM60-65 | 65.00 | 87.00 | 11.00 | 85 | 1233 | 170 | 2465 | - | 4.20 | 31 | - | Yes | 1 |
| 16BM-DRAGAM60-75 | 75.00 | 103.00 | 14.00 | 85 | 1233 | 170 | 2465 | - | 5.20 | 31 | - | Yes | 1 |
| 16BM-DRAGAM60-102 | 100.00 | 128.00 | 14.00 | 85 | 1233 | 170 | 2465 | - | 8.00 | 31 | - | No | 1 |
| 16BM-DRAGAM60-127 | 125.00 | 153.00 | 14.00 | 85 | 1233 | 170 | 2465 | - | 9.90 | 31 | - | Yes | 1 |
