| Item Code | ID | OD | Wall Thickness | Working Pressure | Working Pressure | Bursting Pressure | Bursting Pressure | Bending Radius | Weight | Standard Length | Vacuum Pressure | Ex-Stock | MOQ |
| MM | MM | MM | Bar | PSI | Bar | PSI | MM | Kg/Mtr | Mtr. | Bar | -- | Mtr. | |
| 3SBL20 | 19.00 | 33.00 | 7.00 | 10 | 145 | 30 | 435 | - | 0.67 | 61 | - | No | 61 |
| 3SBL25 | 25.00 | 39.00 | 7.00 | 10 | 145 | 30 | 435 | - | 0.84 | 61 | - | No | 61 |
| 3SBL32 | 32.00 | 48.00 | 8.00 | 10 | 145 | 30 | 435 | - | 1.36 | 61 | - | No | 61 |
| 3SBL38 | 38.00 | 56.00 | 9.00 | 10 | 145 | 30 | 435 | - | 1.52 | 61 | - | No | 61 |
